Module Type:Digital Output
Model Number:AB 2080-OB4
Rated Voltage:24V DC
Number of Channels:4
Operating Temperature:-25°C to 60°C
Response Time:≤10ms
Current Rating per Channel:5A @ 24V DC
Operating Current:≤20mA
Relay Contacts:SPDT (Single Pole Double Throw)
Insulation Resistance:≥100MΩ
Leakage Current:<1μA
Housing Material:Aluminum
Enclosure Type:IP20
Dimensions:W x H x D (mm)
:90 x 100 x 35
Weight:0.2kg
Introducing the AB 2080-OB4 Digital Output Module, an indispensable tool for achieving precise control in industrial automation systems. This module boasts a robust design capable of handling demanding conditions, ensuring reliability and efficiency in a wide range of applications.
With its compact size and versatile features, the AB 2080-OB4 seamlessly integrates into various control setups, enhancing system performance with its high-speed response capabilities. Its ability to operate within extreme temperatures (-25°C to 60°C) makes it suitable for harsh environments found in manufacturing, process control, and other industrial sectors.
Each channel of the AB 2080-OB4 is equipped with SPDT relay contacts, providing reliable switching and control functions. The high insulation resistance and low leakage current ensure safety and minimize the risk of unwanted electrical interference, making it ideal for sensitive systems.
Constructed from high-quality aluminum, this module is lightweight yet durable, offering excellent heat dissipation properties for prolonged use without overheating. Its IP20 enclosure type protects against dust and light splashes, further enhancing its suitability for industrial applications.
Installation is straightforward and compatible with most PLCs and control panels, thanks to its standard mounting holes and compatibility with industry-standard connectors. This module comes with comprehensive documentation and support, ensuring easy integration and quick setup for your automation projects.
